7.2.2

Terminal assignment

Connection is solely by means of device plug →  27.
7.2.3

Available device plugs

Device version: Modbus RS485, 2 switch outputs (batch), 1 status output, 1 status
input
Order code for "Output, input", option MD:
Modbus RS485, 2 switch outputs (batch), 1 status output, 1 status input
Version 1: Status input via connection A/B
A
2
8
3
1
4
7
6
5
A
+
E
-
 10 Connection to device
A Coupling: Supply voltage, Modbus RS485, status input
B Connector: Supply voltage, Modbus RS485, status input
C Coupling: Switch output (batch)
D Connector: Switch output (batch)
E PELV or SELV power supply
V1 Valve (batch), level 1
V2 Valve (batch), level 2
1 to Pin assignment
8
RSE 8
M12x1
B
2
8
3
1
4
4
7
6
5
B
1
2
3
4
5
6
7
8
Electrical connection
RSE 5
M12x1
C D
1 1
5
2 2
3 3
C D
1
2
3
4
5
5
4
V2
V1
