Technical data
Electromagnetic
compatibility (EMC)
Medium temperature range
Medium pressure range
Medium density
Pressure-temperature
ratings
Sensor housing
3) The cleaning refers to the measuring instrument only. Any accessories supplied are not cleaned.
64
Options
Oil- and grease-free version for wetted parts, without declaration
Order code for "Service", option HA
Observe the maximum medium temperatures →  64
As per IEC/EN 61326
Details are provided in the Declaration of Conformity.
This unit is not intended for use in residential environments and cannot guarantee
adequate protection of the radio reception in such environments.
16.9

Process

Sensor
–40 to +130 °C (–40 to +266 °F)
Cleaning
+150 °C (+302 °F) for a maximum of 60 min for CIP and SIP processes
Seals
No internal seals
Max. 40 bar (580 psi), depending on the process connection
DN
[mm]
1
2
4
8
15
25
40
For an overview of the pressure-temperature ratings for the process connections, see
the Technical Information
The sensor housing is filled with dry nitrogen gas and protects the electronics and
mechanics inside.
• The housing does not have a pressure rating classification.
• Reference value for the pressure loading capacity of the sensor housing: 16 bar (232 psi)
For the dimensions and installation lengths of the device, see the "Technical
Information" document, "Mechanical construction" section
3)
[in]
¹⁄₂₄
¹⁄₁₂
¹⁄₈
³⁄₈
½
1
1 ½
Dosimass Modbus RS485
ρ
max
[kg/m 3 ]
3 150
3 100
3 100
4 548
4 900
4 270
4 700
