Technical data
Current consumption
Power supply failure
Electrical connection
Potential equalization
Cable specification
Reference operating
conditions
Maximum measurement
error
60
Order code for "Output, input"
Option MD: Modbus RS485, 2 switch outputs (batch), 1 status output, 1
status input
1) Per switch output used (batch) 500 mA, status output 100 mA
Switch-on current
Option MD: Modbus RS485, 2 switch outputs (batch), 1 status output, 1 status input
Max. 1.2 A (< 15 ms)
• Totalizers stop at the last value measured.
• Configuration is retained in the device memory.
• Error messages (incl. total operated hours) are stored.
→  29
→  30
→  26
16.6

Performance characteristics

• Error limits based on ISO 11631
• Water
• +15 to +45 °C (+59 to +113 °F)
• 2 to 6 bar (29 to 87 psi)
• Data as indicated in the calibration protocol
• Accuracy based on accredited calibration rigs according to ISO 17025

Installation

• Measuring device is grounded.
• The sensor is centered in the pipe.
To obtain measured errors, use the Applicator sizing tool →  55
o.r. = of reading; 1 g/cm³ = 1 kg/l; T = medium temperature
Base accuracy
Bases for calculation →  62
Mass flow and volume flow (liquids)
±0.15 %
Density (liquids)
Under reference conditions
[g/cm³]
±0.0005 g/cm³
Field density adjustment
[g/cm³]
±0.0005 g/cm³
Dosimass Modbus RS485
Maximum
current consumption
1)
100 mA + 1 100 mA
Standard density calibration
[g/cm³]
±0.0025 g/cm³
