Measuring tubes

DN 1 to 4 mm (¹⁄₂₄ to ¹⁄₈")
Stainless steel, 1.4435 (316/316L)
DN 8 to 40 mm (³⁄₈ to 1 ½")
Stainless steel, 1.4539 (904L)
Process connections
DN 1 to 4 mm (¹⁄₂₄ to ¹⁄₈")
½" Tri-Clamp:
Stainless steel, 1.4435 (316L)
DN 8 to 40 mm (³⁄₈ to 1 ½")
All process connections:
Stainless steel, 1.4404 (316/316L)
Available process connections →  67
Seals
Welded process connections without internal seals
Accessories
Sensor holder
Stainless steel, 1.4404 (316L)
Fixed flange
• EN 1092-1 (DIN 2501 / DIN 2512N)
• EN 1092-1 (DIN 2501)
Clamp connections
1" clamp according to DIN 32676
Tri-Clamp
• ½" Tri-Clamp
• ½" Tri-Clamp BS4825-3
• ¾" Tri-Clamp
• 1" Tri-Clamp
Threaded adapter
• DIN 11864-1 Form A
• DIN 11851
• ISO 2853
Process connection materials →  67
All data refer to parts in contact with the medium. The following surface roughness
categories can be ordered.
• Ra = 0.76 µm (30 µin)
max
• Ra = 0.38 µm (15 µin)
max

16.11 Operability

Can be operated in the following languages:
Via "FieldCare", "DeviceCare" operating tool: English, German, French, Spanish, Italian,
Chinese, Japanese
Technical data
