Control Panel - HOMCOM 823-057V70 Use And Care Manual

Control panel This section explains proper mobile air conditioner operation.
Power button
Timer button
Control panel operation
• Cool,Dehumidify,Fan,
1.Turn on the unit
a)Plug in, then the unit beeps once.
b)Press the" "button,then the unit isturned on.
c)Digital display set temperature.
2.Selection operating mode
Pess the" "button to select a desired mode shown below:
3.Adjust Temperature
The temperature can be set within a range of 16
increase or decrease the temperature 1℃ by pressing once After the temperature is
set, the digital tube displays the set temperature.
4.Adjust Fan Speed
Press the " " button to select a desired fan speed shown below:
5.Power
When you press"
6. TIMER
Press this button to set a timed shutdown
Speed button
Mode button
"button again,the unit will emit "di",stop working.
Timer/Temperature up button
Timer/Temperature down button
℃
to 31℃ by 1℃ Press"+"or"_" button to
8
