- Page 1 IN221100172V01_UK 823-042V70 Mobile air conditioner. IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
- Page 2 CONTENTS Safety--------------------------------------------------------------------1 Identification of parts--------------------------------------------------8 Control panel Remote-------------------------------------------------9 controller Protection--------------------------------------------------11 Maintenance-----------------------------------------------------------13 Trouble shooting ------------------------------------------------------14 Installation Accessories and Select the best location-------------------------15 Installation Install Exhaust Hose and Adapter----------------------------------18 Technical Specification---------------------------------------------- 19...
- Page 3 Safety Before you start: Please read the following instructions carefully and retain for future reference. CAUTION: FIRE, ELECTRIC SHOCK, PHYSICAL INJURY AND PROPERTY DAMAGE HAZARDS. ● When using, assembling and maintaining the air conditioner, always follow these instructions. ● Do not wet the housing or control panel. ●...
- Page 4 ● Never use sources of ignition when searching for refrigerant leaks. Do not use a halide torch (or any other naked flame). ● For leak detection, the use of detergents containing chlorine must be avoided. ● If a leak is suspected, all naked flames shall be removed/extinguished. ●...
- Page 5 ● Pump down refrigerant system, if possible. ● If a vacuum is not possible, make a manifold, so the refrigerant can be removed from various parts of the system. ● Make sure that cylinder is situated on the scales before recovery takes place. ●...
- Page 6 ● Service shall only be performed as recommended by the equipment manufacturer. Maintenance and repair operations requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. ●...
- Page 7 RECYCLING & DISPOSAL The packaging of your new product has a recycle mark on it. Please dispose of it as recycled paper. Waste electrical products should not be disposed of with general household waste. This is to prevent the possible harm to the environment and human wellbeing. Contact your local council or government for information, regarding the collection schemes in your area.
- Page 8 Identification of parts Lower drain port Upper drain port The figures in this manual are based on the external view of a standard model. However, the shape may differ from that of the air conditioner you have selected.
- Page 9 Control Panel This section explains how to use this appliance. Indicators High fan speed Middle fan speed Low fan speed Automatic swing Cool Timer off Dehumidify Timer on Automatic Control Panel Operation ● Automatic, cool,fan and dehumidify. 1. Turn on the unit a) Plug in - the unit beeps once.
- Page 10 To Shift the unit between Celsius and Fahrenheit, hold simultaneously when the appliance is on. The corresponding indicator of °C and °F will light up. 4. Adjust Fan Speed Press the to select a desired fan speed, as shown below. 5.
- Page 11 ● Sleep mode 1. The operation is effective when the unit is under mode. 2. Press the button in mode, then the unit will work under sleep mode and the up centrifugal fan will turn to the low speed automatically (the speed icon light remains on the previous setting).
- Page 12 Remote controller Inserting batteries Slide the cover to open. Be sure the direction is correct. 1. Open the back cover and take off the isolating film on the batteries. 2. Put the batteries inside the slot, with anode and cathode in the right directions.
- Page 13 Protection Operating condition Cooling Dehumidifying Features of protector ● ● Drain water Special reminder: There is condensing water within this unit. The water is partly kept between the condenser and water plate. When the water level rises to the upper level, the float switch and water full indicator (E4) lights on - this is a reminder to drain the water.
- Page 14 1. If the appliance is not being used for long periods, pull out the primary and secondary rubber plug from the port, so the water can drain. 2. Keep the appliance running with the fan for half a day, so the inside can dry and prevent mould.
- Page 15 The following cases may not always be a malfunction, please check suggestions below before asking for service. - The protector trip or fuse has blown. - Wait for three minutes and start again - the protector device may prevent the unit from working.
- Page 17 Installation Installation accessories - Beside a window or door. - There must be at least 60 cm of space between all sides of the unit and the wall. - Fix one end of the air hose to the air outlet, which is on the underside of the appliance.
- Page 18 How to connect the connectors to the Air exhaust duct 1. Extend the air exhaust duct by drawing out the two ends of the duct. 2. Screw the air exhaust duct into its connector. 3. Screw the connector of window into the plastic connector. 4.
- Page 19 Fig. 6...
- Page 21 Technical specifications FDP41-3031ZPR5 4000W 1500W/6.9A 400m /h 220-240V~/50Hz L PA ：54dB(A) ：65dB(A) 29.5kg 440 335 710mm 470X380X880mm R290 18~40 m² 3.15A 250VAC If you have any questions, please contact our customer care center. Our contact details are below: 0044-800-240-4004 enquiries@mhstar.co.uk IMPORTER ADDRESS: MH STAR UK LTD Unit 27, Perivale Park,...
