EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION
ULTÉRIEURE.
ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS.
PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE.
DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
IT _ IMPORTANTE! CONSERVARE IL PRESENTE MANUALE PER FUTURO RIFERIMENTO E
LEGGERLO ATTENTAMENTE.
IN231200061V01_US
823-052V80
US_CA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HOMCOM 823-052V80
Summary of Contents for HOMCOM 823-052V80
- Page 1 IN231200061V01_US 823-052V80 EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION ULTÉRIEURE. ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS. PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE. DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
-
Page 3: Table Of Contents
CONTENT Important safety tips Precautions ..................3 Product introduction Main parts and components ................4 Control panel and remote controller ............... 5 Product operation Placement and installation .......... -
Page 4: Precautions
PRECAUTION Before using this appliance , carefully read this manual • This machine is for household use only. • This machine is for indoor use only. Keep it in a dry environment. • Check the power cord frequently. N ever use this appliance with a damaged power cord, plug or air conditioner. -
Page 5: Product Introduction
PRODUCT INTRODUCTION MAIN PARTS AND COMPONENTS 1. Handle 2. Air inlet (L) 3. Control panel 4. Wind guide bar 5. Caster 6. Remote controller 7. Air inlet (R) 8. Air outlet 9. Dehumidification drainage nozzle 10. Air inlet grille 11. Exhaust duct assembly 12. -
Page 6: Controlpanelandremotecontroller
CONTROLPANELANDREMOTECONTROLLER 1. Power button Press to turn the appliance on and off. 2. Mode button Press to choose between, cooling, wind, dehumidification and heating. NOTE: The cooling model does not have a heating mode. 3. Temperature/ time adjustment button When in cooling mode, press this button to increase/reduce the temperature. -
Page 7: Pl Acement And Installation
PL ACEMENT AND INSTALLATION Placement • Place the appliance on an even and dry surface, ensuring it is at least 50cm away from walls and other objects. Installation • Screw the exhaust duct assembly anticlockwise into the air outlet behind the panel. Screw... - Page 8 Insert the air exhaust hose into the window sealing plate. Adjust the opening width of the window so that it aligns properly with the sealing plate. Length of the sealing plate is adjustable. Incorrect installation • Ensure the exhaust duct remains smooth and properly installed. Incorrect installation can hinder your appliance's performance.
-
Page 9: Operation Method
OPERATION METHOD Cooling mode • When the appliance enters cooling mode automatically or when the cooling mode is selected after powering on, the cooling indicator lights up. • Press the 'Up' or 'Down' to adjust the temperature (16°C-30°C). • Press the 'Speed' button to choose between high, medium and low. Fan mode •... -
Page 10: Cleaning And Maintenance Drainage Method
CLEANING AND MAINTENANCE DRAINAGE METHOD This appliance is equipped with an automatic water vaporisation system. The condenser is cooled by the circulation of condensing water, which enhances cooling efficiency and saves energy. • If the internal vessel becomes full of water, the display screen will show 'FL' and the compressor will automatically stop working. -
Page 11: Intelligent Error Detection
INTELLIGENT ERROR DETECTION Error-detecting code Multi-functional defection Error of the coil's temperature sensor Error of indoor temperature sensor Anti-freezing protection: Temperature of the coil is too low, which means the appliance will automatically shut off. Once the temperature exceeds 8° C, the appliance will resume operating in its previous state. - Page 12 Meaning of crossed–out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact you local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
- Page 13 Before use To prevent damage, place the unit in an upright position for at least 24 hours. Ensure the air outlet and inlet are not blocked, allowing proper airflow. Operate the unit on a stable and even surface to avoid water leakage. Warnings ●Do not connect the appliance to a power supply with an impedance greater than 0.236 ohm.
- Page 14 BEFORE USING THIS APPLIANCE, READ THIS MANUAL CAREFULLY. R290 refrigerant gas complies with European environmental directives. This appliance contains approximately 245g of R290 refrigerant gas Appliance shall be installed, operated and stored in a room with a floor area larger than 11.8 m².
- Page 15 8. Checking refrigerating equipment When replacing electrical components, ensure they are suitable for the intended purpose and meet the correct specifications. Always adhere to the manufacturer's maintenance and service guidelines. If unsure, seek assistance from the manufacturer's technical department. For systems using flammable refrigerants, the following checks should be conducted: •...
- Page 16 12. Cabling: • Check the cabling to ensure it is not exposed to conditions that could cause wear, corrosion, excessive pressure, vibration or other environmental impacts. • Consider the effects of ageing and continuous vibration from sources like compressors or fans. 13.
- Page 17 a) Get to know the equipment and how it works. b) Turn off the electricity to the system. c) Before starting, make sure you have the necessary equipment for handling refrigerant cylinders, personal protective equipment and supervision from a qualified person. Also, ensure the recovery equipment and cylinders meet the appropriate standards.
- Page 18 Symbol Note Explanation WARNING appliance uses flammable refrigerant. If the refrigerant leaks and is exposed to an external ignition source, it creates a fire risk. CAUTION Indicates that the manual must be read carefully. CAUTION Professional service personnel must handle the equipment, following this instruction manual.
