Select the best location
- Beside a window or door.
- There must be at least 60 cm of space between all sides of the unit and the wall.
- Fix one end of the air hose to the air outlet, which is on the underside of the appliance.
- Extend the air hose, ensuring the other end of the air hose has space betweer the
window, door or any other opening.
- Do not block the air outlet or intake.
lnstall exhaust hose and adapter
How to connect the connectors to the Air exhaust duct
1.Extend the air exhaust duct by drawing out the two ends of the duct.
2.Screw the air exhaust duct into the connector of air exhaust duct.
3.Screw the connector of window into the plastic connector.
4.Connect the connector of air exhaust duct to the unit.
