IN231000560V01_UK
823-050V70
Local air conditioners
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Instruction manual
1

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the 823-050V70 and is the answer not in the manual?

Questions and answers

Related Manuals for HOMCOM 823-050V70

Summary of Contents for HOMCOM 823-050V70

  • Page 1 IN231000560V01_UK 823-050V70 Local air conditioners IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Instruction manual...

  • Page 2: Table Of Contents

    Contents I. Attention Matters....................3 II. Features and Components................4 III. Control Setting....................6 IV. Protection function..................8 V. Installation and adjustment................9 VI. Drainage Instructions..................11 VII. Maintenance....................12 VIII. Unit Storage....................12 IX. Troubleshooting...................12 IX. Troubleshooting...................18 X. Addendum....................19 The refrigerant used in mobile air conditioners is the environmentally friendly hydrocarbon R290.This refrigerant is odorless, and compared to the alternative refrigerant, the R290 is an ozone-free refrigerant, and its effect is very low.

  • Page 3: Attention Matters

    I. Attention Matters Warning matters: 1. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. 2. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.) 3.

  • Page 4: Features And Components

    *When moving the machine, make sure that it is in an upright position. *The machine should stay away from gasoline, flammable gas, stoves and other heat sources. *Don't disassemble, overhaul and modify the machine arbitrarily, otherwise it will cause a machine malfunction or even bring harm to persons and properties.
  • Page 5 *Air filtration capability. *Timing switch function. *Protection function of automatically restarting the compressor after three minutes, a variety of other protection functions. The Max operation temperature for the air conditioner Cooling: 35/24℃; heating:20/12 ℃; Temperature operation range: 7-35℃. 2. Component Window Sealing Plate Assembly Exhaust Pipe Assembly...

  • Page 6: Control Setting

    III. Control Setting I. Operation interface: 1: Power Key 2: Mode Key 3:Fan Key 4:Down Key 5: Display Window 6: Up Key 7: Timer Key 8: Sleep Mode Key 9: Swing Key 10: WIFI Indicator 1. Power Key: Press this key to turn on and turn off the unit. 2.
  • Page 7 10.WiFi indicator light 11. Information on the WIFI App “Smart Life - Smart Living” The Smart Life - Smart Living app is available for android and iOS. Scan the corresponding QR code to get directly to the download. NOTE: Depending on the provider, there may be costs involved in downloading the app. Google Play App Store Information on How to Use the App...

  • Page 8: Protection Function

    Instructions of key operation of the high-quality remote control are as follows: 1. Power: Press the key to turn on or turn off the machine. 2. Mode: press the key to switch between cooling, fan, and dehumidification mode. 3. Up: press the key to increase temperature and timing set value.

  • Page 9: Installation And Adjustment

    3.2 Overflow Protection Function: When water in the water pan exceeds the warning level, the machine will automatically sound an alarm, and the "FULL" indicator light will flash. At this point, you need to move the drainage pipe connecting the machine or the water outlet to sewer or other drainage area to empty the water (details see Drainage Instructions the end of this chapter).
  • Page 10 Notes:1) the flat end of the exhaust pipe joints must be snapped into place. 2) The pipe cannot be distorted nor has substantial turning (greater than 45 °). Keep the ventilation of the exhaust pipe not blocked. Figure 2 Figure 3 1.3 Install the body 1) Move the machine with installed heat pipe and fittings before the window, and the distance between the body and walls or other objects shall be least 50 cm (as...

  • Page 11: Drainage Instructions

    Important Notice: The length of the exhaust hose shall be 280~1,500mm, and this length is based on the specifications of the air conditioning. Do not use extension tubes or replace it with other different hoses, or this may cause a malfunction. Exhaust host must be not blocked; otherwise it may cause overheating.

  • Page 12: Maintenance

    VII. Maintenance Cleaning: before cleaning and maintenance, turn off the machine and unplug the plug. 1. Clean the surface Clean with surface of machine with a wet soft cloth. Don't use chemicals, such as benzene, alcohol, gasoline, etc; otherwise, the surface of the air conditioning will be damaged or even the whole machine will bedamaged.
  • Page 13 1) Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
  • Page 14 – Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected against being so corroded. 9) Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures.
  • Page 15 5. Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. 6. Leak detection methods The following leak detection methods are deemed acceptable for systems containing flammable refrigerants.
  • Page 16 equipment. Hoses or lines shall be as short as possible to minimize the amount of refrigerant contained in them. – Cylinders shall be kept upright. – Ensure that the refrigeration system is earthed prior to charging the system with refrigerant. –...
  • Page 17 holding the total system charge is available. All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure relief valve and associated shut-off...

  • Page 18: Troubleshooting

    X.Troubleshooting Do not repair or disassemble the air conditioning by yourself. Unqualified repair will lead to failure of the warranty card, and may cause damage to users or their properties. Problems Reasons Solutions Turn it on after connecting it to a There is no electricity.

  • Page 19: Addendum

    XI. Addendum Schematic diagram for air conditioning (The specific technical parameters of the machine shall be subject to the nameplate on the product) Capillary Condenser Evaporator Compressor Treatment: Don't put the abandoned machine with other unsorted waste together. Such waste shall be placed separately for other special use. If you have any questions, please contact our customer care centre.
