Dakota Digital LED Tail Lights LAT-NR101 Installation Instructions

Led tail lights for 1967-68 rs camaro

MAN# 650195

Kit includes:

1. Remove the original bulb sockets from the housing.

2. Remove the tail light housing hardware so the housing can be taken out of the car. Remove

the housings from the vehicle carefully so the body gaskets are not damaged.

3. Next remove the lens to gain access to the housing. There are six screws that hold the housing

halves together, remove the screws and separate the halves carefully.

67-68 RS Camaro

INSTALLATION INSTRUCTIONS

LAT-NR101

LED Tail Lights for 1967-68 RS Camaro.

MAN# 650195

Table of Contents

Do you have a question about the LED Tail Lights LAT-NR101 and is the answer not in the manual?

Page 1 MAN# 650195 Kit includes: Installation: 67-68 RS Camaro 1. Remove the original bulb sockets from the housing. 2. Remove the tail light housing hardware so the housing can be taken out of the car. Remove the housings from the vehicle carefully so the body gaskets are not damaged. 3.
Page 2 4. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is recommended. 5. Remove the mounting plate from the bottom of the assembly; it is attached with two 3/8” 6-32 machine screws.
Page 3 9. Screw the mounting plate into the mount using the two previously removed 3/8” #6 screws. This will secure the LED assembly into the housing. You are now ready for re-assembly. 10. Repeat the steps above for the second light. 11.
Page 4 This Warranty is in lieu of all other expressed warranties or liabilities. Any implied warranties, including any implied warranty of merchantability, shall be limited to the duration of this written warranty. No person or representative is authorized to assume, for Dakota Digital, any liability other than expressed herein in connection with the sale of this product.
