COMMANDER SERIES REMOTE CONTROL ENTRY SYSTEM
INTRODUCTION
Thank you for purchasing the CMD-9000 Commander from Dakota Digital. This, along
with many other products that Dakota Digital has to offer, represents the latest in electronics
technology for the street rod, classic car, sport truck, or custom vehicle.
The CMD-9000 comes complete with receiver/controller, two key chain transmitters, one
sealed emergency release switch, and three dual relay packs. The unit can be installed and
configured to remotely release the driver's and passenger's door latches, provide up and down
control of both the driver and passenger side window, as well as release the trunk latch or operate
a trunk lift up and down. In addition to this, an auxiliary output is provided for an external relay.
This auxiliary relay can be set up as momentarily on or as latch-on, latch-off.
The system incorporates a self-resetting circuit protection device on the latch release
outputs to protect against short circuits. A safety feature partially disables the system when the
ignition is on to avoid the accidental opening of a door during vehicle operation. With the ignition
on, the only functions that are allowed to work are the control of the power windows. An
emergency release switch can be concealed on the underside of the vehicle to roll the driver's
window down should the door ever be closed with the transmitter on the inside and you on the
outside.
ADDITIONAL TRANSMITTERS
The transmitters supplied with your remote system are serial number coded for security.
They also use a code-hopping system that prevents the transmitter signal from being picked up
and duplicated to eliminate security problems. Each unit can "learn" up to 7 transmitters. It is also
possible to program one transmitter into more than one receiver. If you have more than one
vehicle with the CMD-9000 system you can program all of the transmitters into both units.
Transmitters from other manufacturers, such as car alarm systems, will not work with the CMD-
9000.
RADIO FREQUENCY INTERFERENCE STATEMENT
This device complies with part 15 of FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
CMD-9000
FCC IDENTIFIER: OVBTX-434-5B
1
Advertisement
Related Manuals for Dakota Digital Commander Series
Summary of Contents for Dakota Digital Commander Series
- Page 1 INTRODUCTION Thank you for purchasing the CMD-9000 Commander from Dakota Digital. This, along with many other products that Dakota Digital has to offer, represents the latest in electronics technology for the street rod, classic car, sport truck, or custom vehicle.
-
Page 2: Installation
To eliminate having any wires running through your door jams, use DAKOTA DIGITAL MAGNUM SHOOTERS. Refer to the following diagrams for connection to your particular actuators and power windows. - Page 3 For solenoids which require more than 10 amps, such as Dakota Digital’s PDR-2, an external relay should be used for powering the solenoid. FUSED CONSTANT...
- Page 4 Power window regulators are not included with the remote system base kit. They are available separately from Dakota Digital. This remote system is designed to wire into existing power windows or installed at the same time as power windows are added to the vehicle. Use the diagram which matches the way your power windows are connected.
- Page 5 POWER WINDOW WIRING Driver's Window Emergency Entry Switch BROWN REGULATOR AND SWITCH Special regulator or NOT INCLUDED an additional relay module required for this style SEALED GROUND SWITCH of wiring connection GROUND CONSTANT-ON FUSED +12V BLACK CHASSIS GROUND YELLOW TO CONSTANT-ON FUSED +12V PURPLE PURPLE...
- Page 6 POWER TRUNK LIFT WIRING The trunk lift motor is not included in the base package. These are available from Dakota Digital separately. REGULATOR AND SWITCH NOT INCLUDED WIRE COLORS COMING FROM TRUNK LIFT MAY VARY DEPENDING ON MANUFACTURER. CONSTANT-ON FUSED +12V...
-
Page 7: Power Door Lock Wiring
POWER DOOR LOCK WIRING The trunk raise/lower channels can also be used for power door locks to add more security to the vehicle. The door lock actuators are not included with the base package. These are sold separately if they are needed for your application. FACTORY DOOR LOCK SYSTEM CONSTANT-ON... - Page 8 Buttons 1 and 2 will operate door latch releases instead of window up/down. For solenoids which require more than 10 amps, such as Dakota Digital’s PDR-2, an external relay should be used for powering the solenoids on outputs 3 and 4. (see figure 3.)
- Page 9 Drv. Win. Up/Down Pass. Win Up/Down Activate Auxiliary Output Pass. Door Latch Drv. Door Latch Trunk Raise/Lower Trunk Latch OPERATION FOR MODE 1, DIP switch #1 OFF The key chain transmitter has five buttons. They are referred to below as button 1, 2, 3, 4, and 5.
- Page 10 Drv. Win. Up/Down Pass. Win Up/Down (Trunk Raise) (Trunk Lower) Drv. Door Latch Pass. Door Latch (Trunk Latch) (Auxiliary Output) Activate Alternate Function Shown in ( ) OPERATION FOR MODE 2, DIP switch #1 ON The key chain transmitter has five buttons. They are referred to below as button 1, 2, 3, 4, and 5.
- Page 11 REMOTE SYSTEM TRANSMITTER LOCK FUNCTION Due to the long range of this system, some customers may wish to avoid accidentally pressing a button and opening a door when they are out of sight of the vehicle. Turning Switch #3 on will enable a transmitter lock function.
-
Page 12: Troubleshooting Guide
CMD-9000. If none of these solutions solve the problem, or the problem occurring is not listed here, please call the Dakota Digital technical assistance line at (605) 332-6513 for further assistance or email to dakotasupport@dakotadigital.com.
