Installation Guide | SISO LCL and LC Filters
Terminals
3.5
The markings on the inductor terminals are explained in the following table. The locations of the terminals are shown in the illustrations.
Table 2: Markings on the Terminals
Side
Grid
Drive AC
Drive DC
C
FB
Figure 5: Terminals on the Drive Side Inductor
Figure 6: Terminals on the Grid Side Inductor
6
| Danfoss Drives Oy © 2024.03
Marking
L1, L2, L3
L1' , L2' , L3'
+DC' , -DC'
+DC, -DC
AN477036797705en-000101 / 172K2871A
