Specifications; Technical Data - Danfoss VACON SISO LCL Installation Manual

Installation Guide | SISO LCL and LC Filters
See the terminal locations in
a.
Connect the alarm relay to terminals 1 and 2.
b.
Connect the fault relay to terminals 3 and 4.
c.
Connect the sensor to terminals 5 and 6.

4 Specifications

Technical Data

4.1
Table 3: Specifications
Item
Nominal ratings
Current, I
L
Voltage, U
N
Frequency, F
S
Frequency range
Power losses
Mechanical details
Weight
Cooling requirement
Ambient temperature
Storage temperature
Humidity
Insulation class
Protection level
Pollution degree
Installation altitude
Standards
8
| Danfoss Drives Oy © 2024.03
Figure 6.
Specification
525 A rms
500 V AC
3.6 kHz
50/60 Hz
LC filter: 1900 W at nominal operating point
Grid side inductor: 550 W at nominal current
Drive side inductor: 255.1 kg (562 lb)
Grid side inductor: 62.2 kg (137 lb)
C +C capacitor bank: 26.4 kg (58 lb)
DM FB
C capacitor bank: 4.5 kg (10 lb)
Delta
Forced air cooling, >3 m/s, vertical direction
-30...+70 °C (-22...+158 °F) in operation, derating above 40 °C (104 °F)
-40...+70 °C (-40...+158 °F)
<95% RH, no condensation
H 180 °C (EIS180)
IP00
3, IEC60664-1
< 1000 m (3280 ft) above sea-level without derating
EN 61558-2-20, IEC 61800-5-1, UL 61800-5-1, REACH, RoHS (2011/65/EU + 2015/863),
IEC 62474
AN477036797705en-000101 / 172K2871A
