Installation Guide | SISO LCL and LC Filters
Loose or improperly mounted connections can damage the performance of the filter.
Make sure that all connections are tightened according to the instructions.
l
Cabling between inductors and capacitor banks must not be longer than 2 m.
l
Before connecting cables to the terminals, make sure that the surfaces of the terminals are properly cleaned.
l
If 2 cables/phase are used, it is recommended to connect cables to both sides of the terminals.
l
When routing the cables, avoid abrasion against sharp edges in inductor terminals and the frame of the enclosure.
l
1.
Connect the cables to the drive side inductor L
The terminal size is Ø11 mm (0.43 in). Use tightening torque 30–44 Nm (266–389 in-lb). See the terminal locations in
5.
a.
Connect the grid side AC cables to terminals L1, L2, and L3.
b.
Connect the drive side AC cables to terminals L1' , L2' , and L3' .
c.
Connect the DC terminals of the drive to terminals DC+' and DC-' .
d.
Connect the DC link to terminals DC+ and DC-.
2.
Connect the cables to the C
The terminal size is M10. Use tightening torque 12 Nm (106 in-lb). See the terminal locations in
a.
Connect the terminals L1, L2, and L3 of the capacitor bank to the grid side (terminals L1, L2, and L3) of the drive side
inductor L .
1
b.
Connect the terminals +DC and -DC to the DC-link side (terminals DC+ and DC-) of inductor L
3.
Connect the cables to the C
The terminal size is M10. Use tightening torque 12 Nm (106 in-lb). See the terminal locations in
a.
Connect the terminals L1, L2, and L3 to the grid side (terminals L1, L2, and L3) of the drive side inductor L
4.
If included in the delivery, connect the grid side inductor L
banks.
The terminal size is Ø11 mm (0.43 in). Use tightening torque 30–44 Nm (266–389 in-lb). See the terminal locations in
6.
a.
Connect the L
2
b.
Connect the L
2
5.
If included in the delivery, connect the C
See the wiring diagram in
6.
Connect the ground terminals of all components to PE.
The ground terminal size on the inductors is Ø11 mm (0.43 in). Use tightening torque 55 Nm (486 in-lb).
The ground terminal size on the capacitor banks is M10. Use tightening torque 55 Nm (486 in-lb).
See the terminal locations in
