Installation Guide | SISO LCL and LC Filters
1
Drive side inductor
3
C +C capacitor bank
DM FB
Checking the Shipment
1.3
Before delivery, the VACON® SISO LCL/LC Filter has been run through several demanding factory tests.
1.
Examine the packaging and the filter components for transport damage.

If the product was damaged during transport, contact the cargo insurance company or the carrier.
2.
Make sure that the items supplied and the information on the product label correspond to the order confirmation.

If the shipment does not match your order, contact the vendor immediately.
3.
If the installation of the equipment is going to be in the future, cover and store the filter in a clean and dry location.

After storage and before installation, make sure that there is no condensation on the internal components of the filter.

2 Mechanical Installation

Safety
2.1
SHOCK HAZARD FROM THE CAPACITORS
The capacitors can have hazardous charge even if electric power is switched off. Contact with this voltage can
lead to death or serious injury.
l
SHOCK HAZARD
This IP00 filter does not provide protection against direct contact to hazardous live parts. Touching any of the
power connectors during operation can lead to death or serious injury.
Install the filter inside a supplementary enclosure or in a restricted-access area which provides
l
appropriate protection against electric shock.
BURN HAZARD
The filter is hot during operation.
Do not install the filter on a combustible surface.
l
Do not touch the filter when hot.
l
This guide is intended for use by qualified personnel who are experienced in the operation and maintenance of power quality filters.
The personnel involved in the operation and maintenance of this filter must be aware of the necessary safety precautions for this type of
equipment because of the high voltages required by the application.
2
| Danfoss Drives Oy © 2024.03
After disconnecting the filter from the supply, wait 5 more minutes before doing any work on the filter.
Do not open the doors or covers of the enclosure before this time has expired.
After expiration of this time, use measuring equipment to ensure that no voltage is present.
Always ensure the absence of voltage before starting any electrical work.
2
Grid side inductor (only included in LCL filter)
4
C capacitor bank
Delta
DANGER
DANGER
CAUTION
AN477036797705en-000101 / 172K2871A
