Confer Plastics CURVE STEP CCX-AG Assembly, Installation And Use Manual page 4

Step 13
To install the lower
handrail posts [E] first
locate the openings on
part [A] just below the
second tread marked
with #4. Next insert the
tabs on part [E] all the
way into the openings
then tap down with a
rubber mallet until
seated. Repeat to
install the other part [E].
Step 15
Place one of the deck
connectors [F] over
the upper handrail
post and slide down.
Check to make sure
side marked
[This Side down] is
facing downward.
Repeat to install the
second part [F]
Step 16 (Cont.)
With your Curve step fully
assembled locate the [4]
recessed screw locations on
the top tread. With a cordless
drill, at each of these [4]
locations drill a
small 1/8" pilot
hole completely
through the tread
and into the
sidewall below.
WARNING!
Using a corded drill near pool
may result in electrocution.
Step 17
With a helper place the pool step into swimming pool.
WARNING!
Pool step will be heavy. Have additional
help. Do not attempt to place the step by yourself.
Hold the step under water at a slight angle until all the air
bubbles stop. Tilt the step in the other direction until all
the air bubbles stop. Be patient this process will take a
few minutes. If the pool step is still floating all of the air is
not out. Lean step to the side again until air bubbles stop.
4
Step 14
To install the upper
hand rail posts [E]
first locate the
openings on panel
extension [D]
marked with the #4.
Next insert the tabs
on part [E] all the
way into the
openings then tap
down with a rubber
mallet until seated.
Repeat to install the
other part [E] .
Step 16
Place handrails [G]
over the top of hand-
rail posts, push down
to lock in place.
Step 16 (Cont.)
Using a Phillips head screwdriver install one of the
#10 x 1-1/4" stainless screws at each location [4 total].
[HAND TIGHTEN ONLY]
Step 18
With the step in place and positioned about 1 inch away from
the inside of pool wall [back of step must not touch pool liner]
extend the two deck connectors onto the pool deck and attach
using 2-#10 x 1-1/4" self tapping screws in each connector.
These screws should be spaced as far apart as possible using
the holes provided in the deck connector. Next, attach the two
deck connectors to the handrail posts using 2-#10 x 1-1/4"
screws in each post.
