SAVE THESE INSTRUCTIONS

DEALER/INSTALLER: GIVE TO HOMEOWNER

MODEL PES-G GATE ASSEMBLY

Can be used on Pool Entry System, SIG System and STEP Enclosure Kit

ASSEMBLY AND INSTALLATION MANUAL

NEW!!

Now with

Automatic Gate Closer!

WARNING: GATE MUST BE PADLOCKED WHEN NOT IN USE.

CONFER PLASTICS, INC.

Need help?

Do you have a question about the PES-G and is the answer not in the manual?

Page 1 SAVE THESE INSTRUCTIONS DEALER/INSTALLER: GIVE TO HOMEOWNER MODEL PES-G GATE ASSEMBLY Can be used on Pool Entry System, SIG System and STEP Enclosure Kit ASSEMBLY AND INSTALLATION MANUAL NEW!! Now with Automatic Gate Closer! WARNING: GATE MUST BE PADLOCKED WHEN NOT IN USE.
Page 2 POOL ENTRY SYSTEM GATE ASSEMBLY MODEL # PES-G BILL OF MATERIALS #10 x 1-1/4” #7 x 1/2” Parts List Required Part # Self-tapping Self-tapping Gate 6-Gate-01 Screw Screw Hinge Mounting Post 6-Gate-02 Latch Mounting Post 6-Gate-03 Tools Required Hardware Pack...
Page 3 Install the gate closer in the indented portion provided on the hinge post. Follow the directions provided The PES-G now includes a gate closer. with the gate closer package. Mount the closer on the flat recessed are DO NOT use the slide plate.
Page 4 CONFER PLASTICS, INC. LIMITED, PRO-RATED WARRANTY Confer Plastics, Inc. warrants their swimming pool ladders to be free from defects in workmanship for one year from date of purchase. After the first year the cost to replace a part is as follows:...
