Connectors
P1: CoreSight 20 connector
CoreSight 20 connector P1 exposes debug and trace signals and has the following pinout on the
Emulation Adapter side:
Signal
CVDDA
GND
GND
NC
GND
GND
GND
GND
GND
GND
Signal Direction is described from the BlueBox perspective.
Be aware that debug and trace signals from the Emulation Adapter superset device are
not connected to the target board. They are exposed only to the connectors on the
Emulation adapter.
Pin
1
3
5
7
9
11
13
15
17
19
Debug and Trace CoreSight 20 connector pinout
Pin
2
4
6
8
10
12
14
16
18
20
www.tasking.com
Signal
TMS_SWDIO
TCK_SWDCLK
TDO_SWO
TDI
RESETn
TRACECLK
TRACEDATA[0]
TRACEDATA[1]
TRACEDATA[2]
TRACEDATA[3]
