Setting the jumper if VAREF2 is present on the device may prevent establishing a de-
bug connection or, in the worst case, can damage the Target board.
P2: Power supply configuration
Power supply of the Emulation Adapter is configured via the unshrouded 26-pin 2.54 mm
header (P2).
Signal direction
Target board
Target board
Target board
Target board
Target board
Target board
Not connected
Not connected
Not connected
Not connected
Ground
Ground
Ground
By default, all jumpers are set to connect user target power supply to the microcontroller resid-
ing on the Emulation Adapter. Only pins 1-2, 3-4, 5-6, 7-8, 9-10 and 11-12 must be bridged, but
for the convenience and ease of use, all jumpers are set, except for pins 25-26.
Pin 26 is the polarizer key preventing incorrect connection of the IEA-PS Power converter, when
being plugged in.
If a different power source is used (e.g., a Standalone operation), remove all jumpers and apply
3V3 or 5V to:
·
VEXT (pin 2),
·
VDDM (pin 4),
·
VAREF1 (pin 6),
Enclosed Power supply package (Power converter and Power adapter) simply plugs into the P2
header row, providing the necessary power supply for Emulation Adapter operation. LED1 indic-
ates if power is supplied to the Emulation Adapter.
Refer to the microcontroller documentation for more details about power voltage designations.

Connectors

Be aware that debug and trace signals from the Emulation adapter superset device are
not connected to the target board. They are exposed only to the connectors on the
Emulation adapter.
P1: DAP
P1 connector exposes DAP debug interface.
Signal Dir- Signal Description
ection
I Reference Voltage
Ground
Ground
Signal Pin
TVEXT 1
TVDDM 3
TVAREF1 5
TVAREF2 7
TVEVRSB 9
TVFLEX 11
NC 13
NC 15
NC 17
NC 19
GND 21
GND 23
GND 25
P2 Signal description
·
VAREF2 (pin 8),
·
VEVRSB (pin 10),
·
VFLEX (pin 12).
Signal Pin
Vref 1
GND 3
GND 5
Pin Signal
2 VEXT
4 VDDM
6 VAREF1
8 VAREF2
10 VEVRSB
12 VFLEX
14 NC
16 NC
18 NC
20 NC
22 GND
24 GND
26 KEY
Pin Signal Signal Description
2 DAP1
4 DAP0
6 DAP2 Optional 2d DAP Data pin
Signal direction
Emulation device
Emulation device
Emulation device
Emulation device
Emulation device
Emulation device
Not connected
Not connected
Not connected
Not connected
Ground
Ground
Signal Dir-
ection
DAP Data pin
DAP clock
I/O
O
I/O
