Connectors

P1: Nexus trace port
38-pin Mictor connector P1 exposes Nexus trace port and has the following pinout:
Signal
NC
NC
MDO9
NC
RSTIN
TDO
MDO10
TCK
TMS
TDI
NTRST
MDO11
NC
NC
NC
NC
NC
NC
NC
Signal Direction is described from the BlueBox perspective.
Be aware that debug and trace signals from the Emulation adapter superset device
are not connected to the target board. They are exposed only to the connectors on the
Emulation adapter.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
38-pin Mictor pinout
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Signal
NC
NC
NC
MDO8
EVTIN
Vref
NC
MDO7
MDO6
MDO5
MDO4
MDO3
MDO2
MDO1
MDO0
EVTO
MCKO
MSEO1
MSEO0
