The device is intended for permanent connection to a heating system.
Please note the following when connecting:
• Before connecting the device, familiarize yourself with the specific structure of the
heating system. Please contact the manufacturer if you need assistance.
• Make sure that the installation work is carried out professionally and that the result
complies with the relevant rules and regulations.
In the bypass process, a partial volume flow of the water of a heating system
is routed through the device.
During treatment, we recommend switching on the system pumps to ensure
to achieve the fastest possible mixing.
The following figure shows an example of connecting the device in bypass
Procedure:
Figure 7-2: Connection diagram for bypass method
> Transport, installation and commissioning
Connection in the main return
Distance at least 100 cm
Sideflow Clean Pro
