Single Wide Screen TV Desk Mount
Instruction Manual
SKU: STAND-V155C/CW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v155c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V155CW
Summary of Contents for Vivo STAND-V155CW
- Page 1 Single Wide Screen TV Desk Mount Instruction Manual SKU: STAND-V155C/CW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v155c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Assembly Steps
WARNING! TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 66lbs Failure to do so may result in serious injury. (30kg) If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. - Page 3 STEP 2 - Clamp Installation - Continued STEP 2 - Grommet - Continued To secure Lower Pole (B) to Clamp (E), tighten the set screws on Clamp using 3mm Allen Wrench (T-A). Remove protective film from Pads (I) and apply evenly throughout the bottom of Grommet Plate (H). Slide Pole Cable Clip (F) and Plastic Cover (G) onto Lower Pole (B) and thread Pole into Grommet Plate (H).
- Page 4 STEP 3 STEP 3 - Continued Measure the VESA pattern on your display to determine the correct installation orientation needed. 400x300mm & 300x200mm Follow instructions that match your VESA pattern below: To accommodate a 400x300mm or 300x200mm VESA pattern setup, install Extension 75x75mm up to 200x200mm Arm Set (K) to inner holes on VESA Plate (A) using M6x8mm Screws (S-A) and a Phillips screwdriver.
- Page 5 STEP 5 STEP 4 Slide your display onto Upper Pole (B) and tighten collar on VESA Plate (A) using 6mm Allen Flat Monitors: Wrench (T-B). Secure VESA Plate assembly to back of your display using appropriate Screws (M-B, M-B), Washers (M-F, M-G) and a Phillips screwdriver.
- Page 6 Adjust as Desired To adjust the tilt, use Wrench (T-C) to loosen the side bolts on the VESA Plate (A). Tilt can be adjusted -15° to +15°. When desired viewing angle is acheived, tighten bolts on VESA Plate (A) to lock in place.
- Page 7 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
