Single Wide Screen TV Desk Mount
Instruction Manual
SKU: STAND-V155C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v155c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-V155C
Summary of Contents for Vivo STAND-V155C
- Page 1 Single Wide Screen TV Desk Mount Instruction Manual SKU: STAND-V155C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v155c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 66lbs Failure to do so may result in serious injury. (29.94kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Place pole cap (C) onto pole (B). STEP 2 OPTION A: Clamp Installation Slide cable management clip (E) and decorative cover (F) onto pole (B). Then thread pole (B) into base of clamp (D).
- Page 4 STEP 2 (Continued) OPTION B: Grommet Base Installation Remove screw and plate from clamp (D) as shown in diagram. Apply rubber pads (H) to the bottom of grommet base (G) as shown in diagram. Slide cable management clip (E) and decorative cover (F) onto pole (B).
- Page 5 STEP 4 OPTION A: Flat Back Monitor Attach VESA plate (A) to back of TV with screws (M-A, M-B) and washers (M-F, M-G). Make sure the two keyholes on back have the small end facing up. M- A M- B M- F M- G OPTION B: Curved Back Monitor...
- Page 6 STEP 5 Insert bolts (O) into pole (B) at desired height, making sure there are 3 holes unused between bolts. Thread nuts (P) onto bolts leaving 3mm of thread exposed behind bolt heads. Hang VESA plate (A) with TV onto bolts, and tighten with 4mm Allen wrench (K) and wrench (Q). 105mm STEP 6 Store allen wrenches (J, K) in cable clip (E) as shown in diagram.
- Page 7 STEP 7 Manage cables using cable clip (E). Adjust tilt and swivel of TV. +15° -15°...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
