Summary of Contents for ACME Ellipsoidal 300 CW

  • Page 2: Table Of Contents

    CONTENTS 01/ Safety Instructions ....................2 02/ Technical Specifications ..................4 03/ Control Panel ......................7 04/ Fixture Installation ....................8 4.1 The Unit Construction ..................8 4.2 Lens Installation ....................8 05/ How To Set The Unit ....................9 5.1 Main Functions ....................
  • Page 3: 01/ Safety Instructions

    01/ Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
  • Page 4 DO NOT touch any wire during operation as there might be a hazard of electric shock.  Avoid entanglement of the power cord with other wires.  In the event of serious operating problem, stop using the unit immediately.  Never turn on and off the unit time after time.
  • Page 5: 02/ Technical Specifications

    02/ Technical Specifications Power Voltage 100-240V~ 50/60Hz Power Consumption 335W HD320-B (E-300 MB CW) Light Source HD320-A (E-300 MB WW) HD320 (E-300 MB NW) 5600±200K (E-300 MB CW) Color Temperature 3100±150K (E-300 MB WW) 4000±150K (E-300 MB NW) CRI≥85 (CW); CRI≥90 (WW) Optical CQS≥88 (CW);...
  • Page 6 5° 378x1155x524mm 14.9"x45.5"x20.6"in 11°/14°/19° 276x872x524mm 10.9"x34.3"x20.6"in Dimensions 26°/36° 276x712x524mm 10.9"x28"x20.6"in 50°/70° 276x637x524mm 10.9"x25"x20.6"in 5°/11°/14°/19°/26° 9.6kgs 21.2lbs Weight 36°/50°/70° 9.1kgs 20.1lbs - 5 -...
  • Page 7 Photometric Diagram: - 6 -...
  • Page 8: 03/ Control Panel

    03/ Control Panel 1. DIMMER Manually adjust the dimmer value PRIMARY Primary Mode 2. LED SECONDARY Secondary Mode DMX input present 3. Display To show the various menus and the selected function MENU To enter into move backward or leave the menu ...
  • Page 9: 04/ Fixture Installation

    04/ Fixture Installation 4.1 The Unit Construction 1. Lens Module 2. Framing System 3. Bracket 4. Main Body 5. Clip for Gel Holder (Standard/Optional) 6. Gobo Slot 4.2 Lens Installation Loosen the two screws on the Main Body (MB) and put the Framing System into the MB, then turn the Framing System right.
  • Page 10: 05/ How To Set The Unit

    Put the Lens Module into the Framing System and tighten the Lens Module into the Framing System with two screws. 05/ How To Set The Unit 5.1 Main Functions  To access the control menus, press the [MENU] button.  Navigate the menu structure, using the [ENTER], [ UP] and [ DOWN] buttons. ...
  • Page 11 MENU SUBMENU OPTIONS Primary Pri./Sec. Mode Secondary Pri. Sec. No DMX Status Blackout Last State Backlight Intensity 1-10 (Default=10) Contrast Ratio 1-30 (Default=15) Backlight Auto Off Display Setting Display Inverse English Language Chinese Strobe 0-255 Manual Test Dimmer Value 0-255 LED Temp.
  • Page 12 Dimmer Speed Select Dimmer Speed, press ENTER. Use UP/DOWN button to select Fast or Smooth, confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Dimmer Curve Select Dimmer Curve, press ENTER. Use UP/DOWN button to select Mode 1, Mode 2, Mode 3 or Mode 4, confirm your selection with ENTER.
  • Page 13 Display Setting Enter the control menu and select Display Setting, press ENTER. Use the UP/DOWN button to select Backlight Intensity, Contrast Ratio, Backlight Auto Off, Display Inverse or Language. Backlight Intensity Select Backlight Intensity, press ENTER. Use UP/DOWN button to select a value between 1 (dark) and 10 (bright), confirm your selection with ENTER.
  • Page 14 Manual Test Select Manual Test, press ENTER. Use UP/DOWN button to select Strobe or Dimmer Value, confirm your selection with ENTER. Use UP/DOWN button to select a value between 0 and 255, confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Fixture Information Enter the control menu and select Fixture Information, press ENTER.
  • Page 15 RDM functions: Certain menus of the device and functions can be called up via the RDM protocol. The parameter IDs are implemented as follows for different commands: Command Command Command Parameter ID ‘Discovery’ ‘Set’ ‘Get’ DISC_UNIQUE_BRANCH √ DISC_MUTE √ DISC_UN_MUTE √...
  • Page 16: 06/ Control By Universal Dmx Controller

    06/ Control By Universal DMX Controller 6.1 DMX512 Connection 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.
  • Page 17: Address Setting

    6.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address between 1 and 512 so that the units can receive DMX signal. Press the MENU button to access the control menus, select DMX Address, press the ENTER button to confirm, the present address will show on the display.
  • Page 18 1 Channels (Mode 1): CHANNEL VALUE FUNCTION DIMMER 000-255 0%100% 2D Channels (Mode 2): CHANNEL VALUE FUNCTION DIMMER 000-255 0%100% 000-255 DIMMER FINE 2 Channels (Mode 3): CHANNEL VALUE FUNCTION DIMMER 000-255 0%100% STROBE 000-007 Close 008-015 Open 016-131 Strobe from Slow to Fast 132-139 Open 140-181...
  • Page 19: 07/ Troubleshooting

    07/ Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for troubleshooting: A. The unit does not work and no light  Check the connected power and main fuse.  Measure the voltage. ...
  • Page 20 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 2014/30/EU. EN 55032: 2015+A1: 2020; EN 55035: 2017+A11: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021.

This manual is also suitable for:

E-300 cw
