- Page 1 LED‐GF25 User Manual Please read the instruction carefully before use ...
-
Page 2: Table Of Contents
CONTENTS 1. Safety Instructions....................2 2. Technical Specifications ....................3 3. How To Set The Unit ....................4 3.1 Rear Panel......................4 3.2 Main Function ....................5 4. How to Control the Unit ...................9 4.1 Master/Slave Built In Preprogrammed Function ..........9 4.2 Easy Controller....................10 4.3 DMX Controller....................10 5. DMX512 Configuration ...................11 6. DMX Connection ....................12 7. Troubleshooting......................13 8. Fixture Cleaning......................14 ... -
Page 3: Safety Instructions
1. Safety Instructions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. It’s important to ground the yellow/green conductor to earth in order to avoid electric shock. The unit is for indoor use only and use only in a dry location. The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure that no ventilation slots are blocked. Please disconnect mains power before fuse replacement or servicing. Please replace fuse only with the same type. Please make sure there are not flammable materials close to the unit while operating as it is fire hazard. Please use safety cable when fixes this unit. Maximum ... -
Page 4: Technical Specifications
Caution: There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. Installation: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s ... -
Page 5: How To Set The Unit
Weight: 3.7kgs Dimension: 395 x240 x193mm 3. How To Set The Unit 3.1 Rear Panel ... -
Page 6: Main Function
3. LED: DMX On DMX input present MASTER On Master Mode SLAVE On Slave Mode SOUND Flashing Sound activation 4. Button: MENU To select the programming functions DOWN To go backward in the selected functions UP To go forward in the selected functions ENTER To confirm the selected functions 5. Function Display: Used to show the various menus and the selected functions. ... - Page 7 DMX 512 ADDRESS To select the , press the ENTER button to show the DMX ADDRESS on the display. Use the DOWN/UP button to adjust the address from 1 to 512. Once the address has been selected, press the ENTER button to setup, to go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait for one minute to exit the menu mode. ...
- Page 8 SLAVE MODE To select the , press the ENTER button to show the SLAVE MODE on the display. Use the DOWN/UP button to select the (MASTER), (SLAVE 1, normal) or (SLAVE 2, 2 light show) modes. Once the mode has been selected, press the ENTER button to setup, to go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait for one minute to exit the menu mode. SHOW MODE To select the , press the ENTER button to show the SHOW MODE on the display. Use the DOWN/UP button to select the (Random show), (Show 1) or … or (Show 6) mode. Once the mode has been selected, press the ENTER button to setup, to go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait for one minute to exit the menu mode. SOUND MODE To select the , press the ENTER button to show the SOUND MODE on the display. Use the DOWN/UP button to select the (sound on) or (sound off) mode. Once the mode has been selected, press the ENTER button to setup, to go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait ...
- Page 9 LED DISPLAY To select the , press the ENTER button to show the BALCKOUT MODE on the display. Use the DOWN/UP button to select the (LED display on) or (LED display off) mode. Once the mode has been selected, press the ENTER button to setup, to go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait for one minute to exit the menu mode. DISPLAY INVERSE To select the , press the ENTER button to select the (normal) or (inversion), press ENTER button to setup. Back to the functions without any change press MENU button. AUTO TEST To select the , press the ENTER button to show the TEST on the display and the unit will run a self‐test . To go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait for one minute to exit the menu mode. TEMPERATURE To select the , press the ENTER button to show the TEMPERATURE on the display and the display will show the temperature of the unit . To go back to the functions without any changes press the MENU button again. Hold and press the MENU button for one second or wait for one minute to exit the menu mode. ...
-
Page 10: How To Control The Unit
4. How to Control the Unit Please Note: The Acme Dynamic range of effects, including the Spin, Roller Barrel and Scan, have been designed to operate together to provide superb synchronised coordinated lightshows. For the best results, when using a combination of fixtures in master/slave mode, please make the Roller... -
Page 11: Easy Controller
2‐light show In slave mode, means the unit works as the master unit and means 2‐light show. In order to create a great light show, you can set on the second unit to get contrast movement to each other, even if you have two units only. 4.2 Easy Controller The easy remote control is used only in master/slave mode. By connecting to the 1/4” microphone jack of the first unit, you will find that the remote controller on the first unit will control all the other units for Stand by, Function and Mode selection. . Blackout Blackout the unit 1. Sync. Strobe Function Show 1‐6 Show gobo 2. Async strobe 3. Sound Strobe Sound Show Mode LED On (LED OFF) ... -
Page 12: Dmx512 Configuration
5. DMX512 Configuration 4 Channels Mode: ... -
Page 13: Dmx Connection
6. DMX Connection Unit 1 Unit 2 Unit 3 Unit 4 ... -
Page 14: Troubleshooting
7. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The fixture does not work, no light 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. B. Not responding to DMX controller 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity. 3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the fixture or the previous one. 4. Try to use another DMX controller. 5. -
Page 15: Fixture Cleaning
8. Fixture Cleaning The cleaning must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid. Always dry the parts carefully. Clean the external optics at least every 30 days. Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103‐1: 2009 ; EN55103‐2: 2009; EN62471: 2008; EN61000‐3‐2: 2006 + A1:2009 + A2:2009; EN61000‐3‐3: 2008. & Harmonized Standard EN 60598‐1:2008 + All:2009; EN 60598‐2‐17:1989 + A2:1991; EN 62471:2008; EN 62493: 2010 Safety of household and similar electrical appliances Part 1: General requirements ... - Page 16 Innovation, Quality, Performance ...
