ACME TS-300 CW User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TS-300 CW
TS-300 WW
User Manual
Please read the instruction carefully

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-300 CW and is the answer not in the manual?

Questions and answers

Related Manuals for ACME TS-300 CW

Summary of Contents for ACME TS-300 CW

  • Page 1 TS-300 CW TS-300 WW User Manual Please read the instruction carefully...

  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions ................. 2 2. Technical Specifications ................. 3 3. The Plate for Color Filter & Barn Door Installation ......... 4 4. How To Set The Unit................5 4.1 Control panel ................... 5 4.2 Main Functions ................6 5.

  • Page 3: Safety Instructions

    1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. ...

  • Page 4: Technical Specifications

    ◆DMX, Master/Slave, Manual, Art-Net ◆ 4 dimming curves, 2 optional dimmer speed ◆ 0~100% smooth dimming ◆ Low noise under 35db@1m ◆ Rotating barn door and hanger  Power supply: AC 100~240V, 50/60Hz  Power consumption: 420W  Color Temperature: 5500+200K (TS-300 CW)

  • Page 5: The Plate For Color Filter & Barn Door Installation

    3200+200K (TS-300 WW)  Light Source: 1 × 300W white LED CRI:  ≥ 95 ≥ 95  Weight: 10.5Kgs  Dimension: 340×531×284mm 3. The Plate for Color Filter & Barn Door Installation Fig. 1 ○ At first, please push the Lock Cap button by hand as the arrow , and move away the Lock as the ○...

  • Page 6: How To Set The Unit

    Fig. 2 ○ Secondly, please insert the Barn Door into the outside slot from topside as arrow , and fasten the lock (Note: the Barn Door must be fastened into the inside of the lock’s hook ); then flip down ○...

  • Page 7: Main Functions

    1. Display: Show the various menus and the selected functions. 2. LED: MASTER Master Mode SLAVE Slave Mode DMX input present 3. Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions 4.
  • Page 9 DMX Address Select DMX Address, press the ENTER button to confirm, the present address will blink on the display. Use the UP and DOWN button to adjust the DMX address from 1 to 512. Once the address has been selected, press the ENTER button to save. Hold and press the MENU button about one second or wait for one minute to exit the menu mode.
  • Page 10 minute to exit menu mode. Square Law: Light intensity control is finer at low levels and coarser at high levels. Inverse Square Law: Light intensity control is coarser at low levels and finger at high levels. Linear: The increase in light intensity appears to be linear as DMX value is increased. S-cure: Light intensity control is finger at low levels and high levels and coarser at medium levels.
  • Page 11 Select Contrast Ratio, press the ENTER button to confirm, present mode will blink on the display, use the UP/DOWN button to adjust value from 1 to 30, press the ENTER button to save. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode.

  • Page 12: How To Control The Unit

    Select Firmware Version, press the ENTER button to confirm, the software version will show on the display. Press the MENU button back to exit. Factory Setting Select Factory Setting, press the ENTER button to confirm, present mode will blink on the display. Use the DOWN and UP button to select the No or Yes (Switch back to default settings).

  • Page 13: Dmx 512 Configurations

    Unit 1 Unit 2 Unit 3 Unit 4 Channel mode Address Address Address Address 2 channels 3 channels 5.3 DMX 512 Configurations 2 Channels Mode: CHANNEL VALUE FUNCTION DIMMER 0 ~ 255 0  100% ZOOM 0 ~ 255 0  100% 3 Channels Mode: CHANNEL VALUE...

  • Page 14: Troubleshooting

    1. Connect the fixture together in a “daisy chain” by XLR plug cable from the output of the fixture to the input of the next fixture. The cable cannot be branched or split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system 2.

  • Page 15: Fixture Cleaning

    suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2. Measure the mains voltage on the main connector. 3. Check the power on Lamp. B.
  • Page 17 D eclaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008. &...

This manual is also suitable for:

Ts-300 ww
