Leg Extension Adjustment
The leg extension is secured with a spring-loaded catch pawl (Fig. 13A). Adjustments can be made to the leg
extensions in 1" increments by extending or retracting the inner leg for the optimal angle and to adjust for
the ground surface angle.
1. Pull the spring-loaded catch pawl (Fig. 13A) up to release the inner leg.
2. Extend or retract the inner leg (Fig. 14A) as needed so the steps are parallel to the ground and level
when extended, and unobtrusive while retracted.
3. When the leg is at the desired position, release the spring-loaded catch pawl into the tube and slot
closest to where the inner leg and tube meet to lock them (Fig. 15).
Securing and Storing the Steps
1. If necessary, retract leg extensions. See Leg Extension Adjustment section.
2. Lift up SolidStep 4.0 to its stored position (Fig. 11) until the transport lock engages and clicks into
place.
3. Make sure the transport latch flanges (Page 6, Fig. 5A) are resting against the door frame.
4. Once the transport locks have been engaged, test the locking functionality by shaking the step
assembly to simulate road vibration, making sure that the SolidStep 4.0 is secure.
Rev: 07.25.24
Fig. 13
A
Fig. 15
Page 9
Fig. 14
A
CCD-0008400
