- Page 1 Power Steps 2.0 OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Wiring Diagram Introduction This manual provides instructions for installation of Lippert Power Steps 2.0, which are equipped with a step lockout switch, control unit and permanent magnet motor onto a motorized coach. The control unit is a current sensor as well as a switching device. When the motor assembly moves the step tread to its extended position, or stops moving because of an obstruction such as a curb or the binding of a damaged or bent step frame, the motor draws a larger amount of current. -
Page 3: Safety
Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system. -
Page 4: Installation
Installation Installing the Power Steps Stand to the side of the step during this operation to avoid the moving parts. If necessary, the use of a 12V power source to extend the steps may be used to improve accessibility of the mounting holes in the top plate of the step. -
Page 5: Wiring The Power Steps
Install 3/8"-16 bolts (Fig. 1B) in each corner of the steps. NOTE: Lippert recommends using the front holes and rear slots located along each side of the mounting plate. Place a 3/8" flat washer (Fig. 1C) between the bolt head and mounting location. -
Page 6: Safety Label
Refer to figure 2 for switch and magnet installation recommendations and common magnetic closure styles. NOTE: Appearance of switches may vary depending on OEM. Fig. 2 Door Door Switch Door Switch Magnet 6" minimum Magnet Upper floor level Black Black Black Large magnetic Round magnetic... -
Page 7: Operation
Operation Stepping on a partially extended step may cause damage to the step frame. Do not use the step until the step is fully extended. If the vehicle is driven with the step in the extended position, product and/or property damage may occur. - Page 8 If battery drain is suspected, observe the under-step light while the step is extending. To determine if a control unit is not shutting off, which would also cause a drain on the battery, do as follows: Remove the four-way connector to the chassis and the two-way connector between the step motor and the control unit.
-
Page 9: Wiring Diagram
Wiring Diagram Page 9 Rev: 12.15.21 CCD-0005300... - Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
