Purpose

This document outlines the removal and replacement of the Thule 5200 Awning motor.

Safety

Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This document provides general instructions. Many variables can change the circumstances of any procedure,
i.e. the degree of difficulty involved in the service operation and the ability level of the individual performing
the operation. In the event the skill level required is too advanced or the procedure too difficult, a certified
technician should be consulted before performing the necessary operation. Failure to correctly install, remove
or service the system may result in voiding the warranty, inflicting injury or even death.

Resources Required

• Ladder
• Star screwdriver (various sizes)

Procedure

1.
Extend the awning 12" - 18 " inches (Fig. 1).
2.
Secure the arms on both sides of the awning with adjustable straps (Fig. 2A) to keep the awning from
opening. Secure the straps with duct tape to keep the straps from sliding along the arms.
Rev: 07.11.2022
THULE 5200 AWNING MOTOR
REMOVAL/REPLACEMENT
A
AWNINGS
• Adjustable straps
• Duct tape
Fig. 1
Fig. 2
Page 1
A
CCD-0006247

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thule 5200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lippert Thule 5200

  • Page 1 REMOVAL/REPLACEMENT AWNINGS Purpose This document outlines the removal and replacement of the Thule 5200 Awning motor. Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This document provides general instructions. Many variables can change the circumstances of any procedure, i.e.
  • Page 2 THULE 5200 AWNING MOTOR REMOVAL/REPLACEMENT AWNINGS Remove the two screws securing the motor cover to the motor (Fig 3). Remove the motor cover from the awning roll tube by gently prying it out of the notches (Fig. 4). Fig. 3 Fig.
  • Page 3 As a supplier of components to the RV industry, safety, education and customer satisfaction are our primary concerns. Should you have any questions, please do not hesitate to contact us at 432-LIPPERT (432-547-7378) or by email at customerservice@lci1.com. Self-help tips, technical documents, product videos and a training class schedule are available at lippert.com...
