Lippert SolidStep 4.0 Owner's Manual

Trailer entry step with lift assist
Hide thumbs Also See for SolidStep 4.0:

Advertisement

Quick Links

SolidStep
4.0 with
®
Lift Assist
OWNER'S MANUAL
Scan for product support

Advertisement

loading
Need help?

Need help?

Do you have a question about the SolidStep 4.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lippert SolidStep 4.0

  • Page 1 SolidStep 4.0 with ® Lift Assist OWNER'S MANUAL Scan for product support...
  • Page 2 TABLE OF CONTENTS Introduction Safety Operation Release Steps Leg Extension Adjustment Securing and Storing the Steps Adjusting the Transport Lock Notes Introduction The SolidStep® 4.0 is a trailer entry step assembly with lift assist that can be mounted to the side of any trailer, providing an ease of entry, regardless of level ground.
  • Page 3 From the stowed position (Fig. 1), disengage the transport lock by pulling the transport lock knob (Fig. 1A) to the left. Firmly grasp and pull out the vertically stored SolidStep 4.0 and rest it on the ground (Fig. 2). Adjust leg extensions if needed. See Leg Extension Adjustment section.
  • Page 4 Securing and Storing the Steps If necessary, retract leg extensions. See Leg Extension Adjustment section. Lift up SolidStep 4.0 to its stored position (Page 3, Fig. 1) until the transport lock engages and clicks into place. Make sure the latches (Page 5, Fig. 6A) are resting against the door frame.
  • Page 5 Attempting to engage the transport lock without proper adjustment may cause damage to the door frame or step assembly. To verify the transport lock adjustment is working properly, the SolidStep 4.0 should be in the stored position (Fig. 6). Make sure transport latch flanges (Figs. 6A, 7A, and 8A) are resting against the door frame.
  • Page 6 Do not overtighten the bolts. Overtightening the bolts may damage the threads or cause the bolt heads to break off. Once the transport lock mechanism (Fig. 9A) and the transport latch flanges (Figs. 10A and 11A) are in the correct position, tighten the bolts (Figs. 10B and 11B) with a 7/16" wrench or socket. Once the transport lock has been adjusted, test its functionality by shaking the step assembly to simulate road vibration.
  • Page 7 Notes Page 7 Rev: 07.02.24 CCD-0008520...
  • Page 8 Lippert representative has been provided.  Any unauthorized use shall void any applicable warranty.  The information contained in this manual is subject to change without notice and at the sole discretion of Lippert.  Revised editions are available for free download from lippert.com.
