- Page 1 Project 2000 Sliding Step OWNER'S MANUAL...
-
Page 2: Table Of Contents
Notes Introduction The Project 2000 Sliding Step is a resistant to corrosion, lightweight, and has a thermal breaker in case of high strain. The foot board is constructed of anodized aluminum with anti-slip rubber. Disassembly of the Project 2000 Sliding Step voids the warranty. Contact Lippert to obtain replacement parts. -
Page 3: Safety
Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system. -
Page 4: Operation
Operation Do not walk on the step until it is completely stopped. Do not interfere with the step while in operation. Doing so may cause serious personal injury. Make sure that children are away from the electric step when it is in motion. Park the unit on level ground. -
Page 5: Wiring Diagram
Wiring Diagram Diagram 1 +12V DC adjustment screw Common Button (+12V) Command EXIT Command RETURN Command EXIT Command RETURN "B" connector "A" connector Common Button (+12V) "B" "A" "A" CONNECTOR "B" CONNECTOR Pin N° Description Pin N° Description Button common (+12 V) (-GND) motor - motor +... -
Page 6: For Automatic Opening/Closing Kit
Wiring Diagram For Automatic Opening/Closing Kit Page 6 Rev: 02.08.22 CCD-0004560... - Page 7 Wiring Diagram For Automatic Opening/Closing Kit (Continued) Alert Indicator Step Open: Alert Indicator will be active when ignition is switched on. NOTE: D+ should be a positive line that comes from the vehicle anytime the parking brake is disengaged or the ignition is engaged. Alert Indicator circuit must be filtered to 12V.
-
Page 8: Maintenance
Maintenance Make sure unit is parked on a stable, level surface. Make sure power to the unit is turned off and/or disconnected. Prior to starting maintenance procedures, disconnect power to the step’s electrical system to prevent inadvertent operation of the step. After driving on roads that are salted, wash the step with fresh water. -
Page 9: Notes
Notes Page 9 Rev: 02.08.22 CCD-0004560... - Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
