Validating and Generating a Commissioning Report

7.6
For drives with functional safety option +BEF2, a commissioning report can be generated using MyDrive® Insight. The commissioning
report describes the values set for the safety-related parameters in the drive.
1.
In MyDrive® Insight, go to Device > Setup & Service > Functional safety > Validate report.
2. Go to Device > Setup & Service > Functional safety > Commissioning Report to see the commissioning report.
Ü
After commissioning all safety functions, click the download icon on the upper right corner to download the report as
a PDF file. It is recommended to save a copy of the commissioning report to an external location.
3. Store the acceptance test reports in the logbook of the machine.
The report must include:
A description of the safety application.
¢
A description and revisions of safety components that are used in the safety application.
¢
A list of all safety functions that are used in the safety application.
¢
A list of all safety-related parameters and their values. Listing parameters and values not related to safety is also
¢
recommended.
Documentation of startup activities, with references to failure reports and resolution of the failures.
¢
The test results for each safety function, all safety parameter values including the CRC value of the safety configuration,
¢
dates of the tests, and confirmation by the test personnel.
4. Validate the commissioning report.
a. Check that the hardware and configuration information is correct and that the software versions of safety-related
components and subsystems are correct.
b.
Check that the information of the commissioned module matches the information in the commissioning plan and
commissioning report.
IMPORTANT:
in the logbook of the machine.
32 | Danfoss Drives Oy © 2024.09
After each change or maintenance to the system, new acceptance test reports must be stored
