Operating Guide | iC7 Series Functional Safety
Table 19: 24 V Digital Outputs for STO Feedback
Function
ON state voltage
Off state leakage current
Table 20: Auxiliary Voltages
Function
24 V output, functional safety (X33)
Operating Conditions
10.3
Table 21: Operating Conditions for Functional Safety
Function
Operating temperature
Storage temperature
Air humidity
Operating altitude
Environmental conditions
10.4 Cable Specifications
Table 22: Cable Sizing for Connectors X31, X32
Wire type
Solid
Flexible
Flexible with ferrule w/o plastic sleeve
Flexible with ferrule w plastic sleeve
42 | Danfoss Drives Oy © 2024.09
(continued)
Data
>17.4 V
0.1 mA
Output voltage
Maximum load
Data
According to the AC drive specifications.
-40 °C...+80 °C (-40 °F...+176 °F)
According to the AC drive specifications (non-condensing).
According to the AC drive specifications.
The product must be installed in an environment corresponding to
EN IEC 61800-5-1:2017 PD2 – non-condensing.
For PD2 condensing environments, the product must be installed in IP54/NEMA 12 cabi-
net as per EN IEC 60529 AMD 2:2013 , or similar.
2
Cross-section [mm (AWG)]
0.5–1.5 (24–16)
0.5–1.5 (24–16)
0.5–1.5 (24–16)
0.5 (24)
Data
24 V ±15%
100 mA
Stripping length [mm (in)]
10 (0.4)
10 (0.4)
10 (0.4)
10 (0.4)
