Operating Guide | iC7 Series Functional Safety

Parameters for Safety Functions

4

Overview

4.1
Functional safety configuration is done in MyDrive® Insight, in Setup & Service > Functional safety > Safety configuration. Changing
parameters related to functional safety requires logging in as an admin.
Parameters related to application software, for example, automatic/manual restart behavior after STO deactivation, are included in
parameter group Functional Safety. Factory default values and other preset values are not valid for safety applications as such, and
all parameter values must be checked to ensure that the configuration is suitable for the application. For more information on setting
parameters, refer to application software documentation.
After initial startup and the modification of the configuration or functional safety parameters, a
IMPORTANT:
commissioning test must be performed to verify the functionality of individual safety functions. For more information, see
7.4 Commissioning Test for Safety Function STO
(SS1-t).
The configuration of functional safety features must be done according to the safety system installation and wiring, and consists of the
following steps:
1.
General parameter configuration
2.
Failure configuration
3. System module pairing
4.
STO configuration
5.
SS1-t configuration
6. Saving to device
7. Verifying parameters
8.
Validating the configuration
9.
Generating a commissioning report

General Functional Safety Parameters

4.2
Table 4: General Functional Safety Parameters
(1)
Parameter name
Stable Signal Time (A)
Acknowledge input for IO fail-
ures (B)
Danfoss Drives Oy © 2024.09
and 7.5 Commissioning Test for Safety Function Safe Stop 1 Time-controlled
Selections
1–5000 ms
Not selected
Safe Input (X33)
Default value
10
Not selected
AQ477043679710en-000102 / 172K2965A |
Parameters for Safety Functions
Description
Delay until a signal change to
Low is detected stable.
This parameter specifies a de-
lay in addition to the time
specified for input signal inter-
pretation in the drive.
Specifies the safe digital input,
which can be associated to the
acknowledgment of the IO fail-
ures.
