Operating Guide | iC7 Series Functional Safety
Table 4: General Functional Safety Parameters
(1)
Parameter name
Triggering edge for IO failure
acknowledge (C)
Restart behavior for release of
IO Failure (D)
Acknowledge input for startup
(E)
Triggering edge for startup ac-
knowledge (F)
Manual startup acknowledge
(G)
1) Parameters are identified with letters in the Safety configuration section in MyDrive® Insight. The letter is given in parentheses after the parameter name for each parameter in this
table.

Failure Configuration

4.3
Table 5: Failure Configuration Parameters
(1)
Parameter name
IO Fault mapping (A)
1) Parameters are identified with letters in the Safety configuration section in MyDrive® Insight. The letter is given in parentheses after the parameter name for each parameter in this
table.

Pairing Control Units and Power Units

4.4
Prerequisite:
Control units and power units must be paired to make the system fully functional. Pairing the units establishes safe internal
communication between the units. The pairing may need to be done before starting parameterization. By default, the pairing of the
units for new drives is done at the factory.
A factory reset also resets the pairing.
After performing a factory reset, the control units and power units must be paired again to make the system fully functional.
l
The pairing is done in MyDrive® Insight.
1. In MyDrive® Insight, navigate to Setup & Service > Functional safety > Safety configuration > System module pairing.
18 | Danfoss Drives Oy © 2024.09
(continued)
Selections
Rising edge
Falling edge
Nonsafe Acknowledge re-
quired
Safe Acknowledge required
Not selected
Safe Input (X33)
Rising edge
Falling edge
Direct restart
Nonsafe Acknowledge re-
quired
Safe Acknowledge required
Selections
STO
First instance of SS1
NOTICE
Default value
Rising edge
Nonsafe Acknowledge re-
quired
Not selected
Rising edge
Direct restart
Default value
STO
Parameters for Safety Functions
Description
Specifies the edge for the ac-
knowledgment of the IO fail-
ures.
Specifies the restart behavior
for IO failure.
Specifies the safe digital in-
put, which can be associated
to the acknowledgment of the
startup.
Specifies the edge for the ac-
knowledgment of the IO fail-
ures.
Specifies the restart behavior
for startup acknowledge.
Description
Mapping of fault instance to
IO.
