HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS
Elements cabinets are available with two base options. Depending on the base that you have selected,
your configuration will include one of these two sets of components.
CONSOLE BASE
Base Spanner Tube (C7)
Base Connection Plate (C8)
ROLLING PLINTH BASE
Rolling Plinth Base (C6)
QTY: 2
QTY: 2 Base Leg (C9)
QTY: 1
QTY: 2
NEED ASSISTANCE? customerservice@bdiusa.com | 5
PROCEED TO PAGE 6
Leveler Wrench (T3) QTY: 1
Screw M6 x 75 (H3) QTY: 8
Screw M6 x 12 (H4) QTY: 8
Screw M6 x 12 (H5) QTY: 8
PROCEED TO PAGE 8
Screw M6 x 50 (H2) QTY: 10
