Component List
Designed by Matthew Weatherly.
BDI and Corridor are trademarks of Becker Designed, Inc. All Rights
reserved. ©2015, BDI
Made in China. 8175REV110515v1
corridor
8175
cabinet
A - Phillips Screwdriver
x 1
B1 - Hex Wrench
x 1
B2 - Hex Wrench
x 1
C - Cabinet
x 1
D - 1/4-20 x 10 mm
Machine Screw
x 16
E - Metal Leg
x 2
F - Metal Rail
x 2
G - 1/4-20 x 60 mm
Machine Screw
x 4
H - M4 x 35 mm
Machine Screw
x 4
I - Door Pull
x 2
J - Rubber Bumper
x 7
K - Glass Top
x 1
L - Adjustable Shelf
x 2
M - Back Panel
x 1
a s s e m b l y i n s t r u c t i o n s
bdiusa.com
Product Registration
Registering your product allows us to send you important updates,
service information and helpful hints. Register today, and you will
be entered to win a free Bink mobile media table from BDI.
www.bdiusa.com/product-registration/
Placement and Maintenance
Corridor is designed for indoor use on level floors. Clean wood
veneer with a moist cloth. Clean glass with glass cleaner.
Corridor is engineered for easy assembly. Carefully follow this
procedure to prevent any damage.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as clean carpet.
For missing hardware pieces, please contact BDI Customer Service
at customerservice@bdiusa.com. For all other concerns, please
contact your BDI Retailer.
1
customerservice@bdiusa.com
