- Page 1 REVEAL 1196 ™ END TABLE INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Reveal End Table 1196 from BDI. Your end table has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information to ensure that you get the most out of your product.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for the assembly of this product.
- Page 5 HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS PART # DESCRIPTION Lower Frame QUANTITY PART # DESCRIPTION Case QUANTITY PART # DESCRIPTION Shelf Glass QUANTITY PART # DESCRIPTION Top Glass QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
-
Page 6: Step 1. Attach Legs
ASSEMBLY STEP 1. ATTACH LEGS Attach the (C2) Legs to the (C1) Upper Frame PART/DESCRIPTION using 3 (H1) Screws per leg. Tighten with (T1) Hex Wrench. T1-HEX WRENCH H1-SCREW 6 | BDIUSA.COM REVEAL 1196... - Page 7 STEP 2. ATTACH LOWER FRAME ASSEMBLY Attach the (C3) Lower Frame to the (C2) Legs using 4 (H2) Screws. Tighten with (T1) Hex Wrench. PART/DESCRIPTION T1-HEX WRENCH H2-SCREW Rubber bumper should point down STEP 3. ATTACH CASE ASSEMBLY Place the (C4) Case upside down on the floor. Lift and place the Base Assembly on top of the (C4) Case.
- Page 8 STEP 5. INSTALL TOP GLASS ASSEMBLY Place (C6) Top Glass on the rubber bumpers on top of the Case. The (C6) Top Glass can be identified via a sticker on the bottom surface. 8 | BDIUSA.COM REVEAL 1196...
-
Page 9: Fine Tuning
FINE TUNING LEVEL TABLE Make sure the table is level. Adjust one or more PART/DESCRIPTION of the levelers using (T2) Leveler Wrench to attain a level stance. T2-LEVELER WRENCH down NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 9... -
Page 10: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 11: Warranty
WARRANTY BDI warrants to the original purchaser that for the below-stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty that fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component. - Page 12 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Reveal & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2022, BDI | V.03.03.2022 Made in Turkey.
