Set Fixture Parameters

This section provides instructions to configure and set up the SolaWash 2000. See
the User Interface on page 13
Provide power to the fixture before configuring it. If you do not provide power, the fixture will
use battery power to power the user interface.

DMX Address

Navigate: Main Menu → Address
Set the DMX address for the fixture. The default value is 001.

Info Menu

Set the Time Information
Navigate: Main Menu → Info → Time Info
Parameter
Current Time
Ttl Life Hrs
Last Run Hrs
LED Hours
Timer PIN
Clr Last Run
LED Time PIN
Clear LED Time
View DMX Values for Channels
Navigate: Main Menu → Info → Value Disp.
View the DMX value of each of the fixture's channels (parameters of the fixture). Scroll to the
parameter that you want to view (Pan, Tilt, etc.) and view the value. The DMX value that you
view is the DMX value that displays on the main window of the UI until you select a different
DMX value to view.
14
for information about the navigation buttons.
Value Description
XXXX (Hours) Running time of the fixture from the last time that the
fixture was powered on, shown in hours (h). The
counter resets after the fixture is turned off.
XXXX (Hours) Total running time of the device, shown in hours (h).
XXXX (Hours) Running time of the fixture from the last time that the
run time value was reset, shown in hours (h).
XXXX (Hours) Total running time of the fixture LEDs, shown in
hours (h).
Timer PIN XXX You must enter the Timer PIN in order to access the
Clr Last Run menu item. The default Timer PIN is 038.
• ON This password-protected menu item resets the Last
Run Hrs value. You must enter the Timer PIN to access
• OFF
this menu item.
Select ON to clear the value for the Last Run Hrs
parameter for the fixture.
LED Time PIN XXX You must enter the LED Time PIN in order to access
the Clear LED Time menu item. The default LED Time
PIN is 038.
• ON This password-protected menu item resets the LED
Hours value. You must enter the LED Time PIN to
• OFF
access this menu item.
Select ON to clear the value for the LED Hours
parameter.
Navigate
