Access Service Settings
Navigate: Main Menu → Set → Service PIN
Parameter
Service PIN
RDM UID
Set Display Settings
Navigate: Main Menu → Set → Disp. Setting
Parameter
Shutoff Time
Flip Display
Key Lock
Set the Temperature Scale
Navigate: Main Menu → Set → Temp. C/F
Select the temperature scale for the fixture:
• Celsius (default value)
• Fahrenheit
Configure the Fixture
Value Description
Service PIN XXX You must enter the Service PIN in order to access the
other Service Setting parameters. The default Service
PIN is 050.
Manufacturer ID This password-protected menu item lets you modify
and fixture serial the RDM UID. You must enter the Service PIN to
number access this menu item.
Note: Remote Device Management (RDM) requires
that all RDM devices have a unique identifier (UID)
that consists of the manufacturer ID and serial
number. Modifying this setting can break the RDM
capability of this fixture.
Duplicate RDM UIDs on the same DMX control run
will result in a data collision, causing a
communication failure. Ensure that all fixtures have a
unique RDM UID if RDM functionality is to be used.
If DMX splitters are used and RDM control is to be
used, these splitters must support RDM.
Value Description
02–60 minutes Enter the amount of time the fixture waits after the
last user interface button press until the display goes
to sleep. The default value is 5 minutes.
• ON Flip the display 180° when the fixture is mounted
vertically. The default value is OFF.
• OFF
Shortcut: With the main UI window displayed, press
[>] to flip the display 180°. Press [<] to flip it back to
its original orientation.
• ON Lock the user interface. The default value is OFF.
To unlock the user interface navigation buttons, press
• OFF
and hold the [MODE/ESC] button for three seconds.
