to different sections of the farm. If the voltage on the
fence increases when a section of the farm is turned
off, then investigate that section for possible faults.
There are no lights flashing on the energizer.
Check the power supply. Ensure that the power is
switched on. If the energizer still does not operate,
request your Speedrite service agent to check the
energizer.

Product Specifications

Power Supply
Current Consumption
Fast-Full Power
Fast-Half Power
Maximum Output Voltage
Maximum Output Energy
Stored Energy
Dimensions WxHxD
Weight
Delta 1B
12 V battery
(optional Solar Panel)
70 mA
35 mA
7.9 kV
0.5 J at 700 Ω
0.8 J
240x200x118 mm
(9½x8x4¾")
1.37 kg
(3 lb)

Servicing

This energizer contains no user serviceable parts. It
must be returned to a Speedrite-appointed service
agent for repair. If the supply cord is damaged it
must only be replaced by a Speedrite-appointed
service agent, as a special cord is required.
Delta 2B
12 V battery
(optional Solar Panel)
140 mA
70 mA
8.4 kV
1.0 J at 400 Ω
1.7 J
240x200x118 mm
(9½x8x4¾")
1.37 kg
(3 lb)
Delta 3B
12 V battery
(optional Solar Panel)
340 mA
170 mA
8.4 kV
2.5 J at 200 Ω
4.1 J
240x200x118 mm
(9½x8x4¾")
1.37 kg
(3 lb)
13
