Dimensional Drawings
■Q-Cam remote cable
■J3 branch cable
nac
nac
■J3 branch cable (BNC receptacle)
nac
nac
■Simple J3 cable
nac
nac
L：500±25（mm）
L：500±25（mm）
L：500±25（mm）
6-38
P31<ETHER>
P32<EST2>
P33<IRIG-B>
P34<TRIG2>
P35<EPO>
P36<PWRCNT>
P31<ETHER>
P32<EST2>
P33<IRIG-B>
P34<TRIG2>
P35<EPO>
P36<PWRCNT>
