■Recording Format
Recording Format
■Recording Conditions
Recording Start Conditions
Recording End Conditions
■Recording Trigger Mode
Normal Trigger
■Trigger Timing
START
CENTER
END
CUSTOM
(00419)D
Overwrite recording to the memory configured of a ring buffer
ARM Command (ARM from HXLink or such)
Recording Trigger Vibration (IF connector TRIG IB)
REC Command (Network：REC from HXLink or such)
G Sensor Trigger ( detection of impact by acceleration sensor)
＜Stop Command＞
Q5 recording automatically ends when abnormal temperature is
generated.
Normal recording trigger
The trigger point is about 5% before the beginning of the recording
memory
The trigger point is the center of the recording memory (About 50％)
The trigger point is about 5% before the end of the recording memory
The trigger point is at a preset value (-100～100%) , set at 1%
intervals
4-29
Recorder (Q5)
