NAC Image Technology MEMRECAM Q5 User Manual page 208

Specifications
Pin Arrangement
Pin Arrangement
Pin
Name
No.
1 MDI 0+
2 MDI 0-
3 MDI 1+
4 MDI 1-
5 MDI 2+
6 MDI 2-
7 MDI 3+
8 MDI 3-
9 SYNC1 (~4) OUT
10 SYNC1 (~4) OUT RTN
11 DC1 (~4) OUT
12 DC1 (~4) OUT RTN
13 TRIG1 (~4) OUT
14 TRIG1 (~4) OUT RTN
15 EPO1 (~4) IN
16 EPO1 (~4) IN RTN
17 PWRCNT1 (~4) OUT
PWRCNT1 (~4)
18
RTN
shell FRAME GND
Direction Function ・Input/Output Level
I/O 1000BASE-T Interface
I/O 1000BASE-T Interface
I/O 1000BASE-T Interface
I/O
1000BASE-T Interface
I/O 1000BASE-T Interface
I/O 1000BASE-T Interface
I/O 1000BASE-T Interface
I/O 1000BASE-T Interface
OUT CMOS LEVEL, 5V
OUT SYNC output signal return
OUT DC +30V output
OUT DC +30V return
OUT CMOS LEVEL, 5V
OUT TRIG output signal return
IN TTL
IN EPO input signal return
Open
OUT
5.5V), short
OUT
OUT PWRCNT output signal return
－ Frame ground
6-30
(maximum voltage tolerance
Notes
Isolation
Isolation ground
Camera power
Camera power
Isolation
Isolation ground
Isolation
Isolation ground
Isolation
Isolation ground
