Specifications
■BAT IN connector
Application
Model
Compatible Plug
Power Voltage
Power Consumed
Power Protection
Pin Arrangement
Pin
Name
No.
1 BAT24V IN
2 BAT_TMP
3 BAT24V RTN
shell FRAME GND
Power input
LEMO EGG.2B.303
LEMO FGG.2B.303
DC22.5 - 32V
Battery overcharge protection： 20VDC
Prevents battery from dying by supplying 24V or more of power in DC
IN.
Max of approximately 140W
(external battery sold separately)
Reverse polarity： Internal protection circuit
Overcurrent：Internal protection circuit Approximately 12A
Overvoltage： 35VDC 1 minute
Low voltage： 20VDC
Direction Function ・Input/Output Level
IN DC + Input
－ Thermister
IN DC + Return
－ Frame ground
6-22
Notes
Input DC22.5～
32V
