Specifications
Specifications
■Power Switch
Power Switch
■Sync Signal Switch
MODE Switch
■Status LED
POWER
IRIG
EST
TRIG
ALARM
Rotary style SW (３positions)
○ (OFF) ：
Power OFF
REMOTE：
ON/OFF according to power control signals
Power for Q5 memory backup provided.
｜ (ON) ：
Power ON
Sliding style SW (2 positions)
IRIG：
Set sync signal to IRIG B (DCLS, AM) or SYNC 1kHz
(factory setting)
EST：
Set sync signal to EST
Green：
Power ON
Not lit：
Power OFF
Green：
IRIG B (DCLS, AM) signal or 1kHz input, and locked
(sync switch is IRIG)
Red：
No IRIG B (DCLS, AM) signal or 1kHz input, or input
but not locked.
(sync switch is IRIG)
Not lit：
Sync signal switch set to EST
Green：
Sync signal switch set to EST
Not lit：
Sync signal switch set to IRIG
Green：
After trigger signal input, lit for 1 second (then
not lit)
Or continues to be lit when trigger signal input
continues for less than 1 second
Not lit：
No trigger signal
Red：
When there is an overcurrent, overvoltage, or low
voltage detected in the power line
Not lit：
Normal
6-20
(00419)D
