Range of Settings and Intervals for Exposure Times that can be Set
Frame Rate
(pps)
100
250
500
1,000
1,000
( Advanced
Sampling Mode)

 The control software automatically calculates the exposure times that can be set by the
custom shutter.
 The interval can be set at 1μs but 8～9μs is possible for actual operation with the camera
specifications.
(00419)D
Settings (μs)
Pixels
(width x height)
Max
640×480 9946
640x480 3946
640x456 1946
640x210 946
640x416 946
4-23
Setting Intervals
(μs)
Min
56 1
56 1
56 1
56 1
56 1
