BB1 UNIT

■BB1 UNIT
Extension unit for 4 types of camera heads
 The BB1 UNIT cannot be used when the Q5 is connected to the Q-HUB.
External Dimensions (W×H×D)
Weight of the main unit
Status display on the LED
Mounting screws
Operating temperature and
humidity
Storage temperature and
humidity
Vibration
Impact
Power consumed
Connector
Cable
Safety Standards
Electromagnetic Compatibility
(00419)D
Approximately W42 × H31.4 × D143mm (excluding the connector and
protruding parts; cables not included)
Approximately 1.8kg (including cables)
Approximately 0.2kg (not including cables)
Green：Normal
Red：Abnormal communication with DRP
Orange：Abnormal communication with camera
Not lit：No power
4 locations on the top and bottom M6 Depth of 6mm
4 locations on the side, 8 locations on the back M4 Depth of 6mm
0～40℃、30～80%RH (no condensation)
-10～60℃、20～80%RH (no condensation)
Conforms to MIL-STD-810C METHOD 514.2 CATEGORY b2
(RANDOM VIBRATION ENVELOPE) FIGURE 514.2-2A
Half sine, 11msec, 150G (but only 100G in the direction the
connector is removed)
Approximately 2W (supplied from the Q5)
Plug：LEMO FGG.3B.326 equivalent product (pigtail) or
ODU SX3L0C-P26PFG0-0001 (pigtail)
Receptacle：LEMO EGG.3B.326 or
ODU G13L0C-P26LFG0-0000
Pigtail configuration：Length of approximately５ｍ
Diameter Approximately 12.9mm
EN60950
EN55022、EN55024、FCC Part 15 Class A
5-3
BB1 UNIT
