■Connect the ARMOUT cable
Since the ARM status output signals are output by the ARM OUT connector, it is possible to verify the Q5
ARM status.
 The ARM OUT connector is a separate dedicated connector from the ARM status output of the
IF connector.
 ARM OUT output specifications.（A 4-40）
(00419)D
1
Connect the ARM OUT cable to the Q5

Line up the ARM OUT cable plug with the ARM OUT connector
on the Q5, plug it in and turn to the right. Make sure it is
locked.
2-9
Connect the Equipment and Cables
