Features of This Unit

The MEMRECAM ACS-3 is a high speed digital camera designed to analyze the phenomenon of
movements that are faster than the eye can see.
High Speed · High Resolution Image Sensor
Equipped with a highly sensitive CMOS sensor to enable high speed operation at high
resolutions.
The ACS-3E is capable of recording a maximum of 14,000 frames per second at 1280 × 896
pixels, a maximum of 25,000 frames per second at 1280 × 480 pixels, a maximum of 40,000
frames per second at 1280 × 272 pixels, and a maximum of 220,000 frames per second at
1280 × 16 pixels. The ACS-3 M16E is capable of recording a maximum of 14,000 frames per
second at 1280 × 896 pixels, a maximum of 25,000 frames per second at 1280 × 496 pixels,
a maximum of 40,000 frames per second at 1280 × 288 pixels, and a maximum of 220,000
frames per second at 1280 × 16 pixels.
The ACS-3 is capable of filming a maximum of 14,000 frames per second at 1280 × 896 pixels,
a maximum of 25,000 frames per second at 1280 × 480 pixels, a maximum of 40,000 frames
per second at 1280 × 272 pixels, and a maximum of 350,000 frames per second 1280 × 16
pixels. The ACS-3 M16 is capable of filming a maximum of 14,000 frames per second at 1280
× 896 pixels, a maximum of 25,000 frames per second at 1280 × 496 pixels, a maximum
of 40,000 frames per second at 1280 × 288 pixels, and a maximum of 400,000 frames per
second 1280 × 16 pixels.
Also, the custom frame rate function enables the frame rate to be set in units of 10 frames per
second for 50 frames per second and higher.
ACS-3 M16E/ACS-3 M16 improves image quality in Recording priority "QUALITY".
High Sensitivity
Recording is possible in a variety of conditions.
Sensitivity Mono ISO 40,000
Mono ISO 50,000
Mono ISO 100,000 : ACS-3 M16E /ACS-3 M16 (SENSITIVE)
Color ISO 8,000
Color ISO 20,000
(00471)H
: ACS-3 M16E/ACS-3E M16(QUALITY)
: ACS-3 /ACS-3E
: ACS-3 M16E /ACS-3 M16 (QUALITY)
: ACS-3 M16E /ACS-3 M16 (SENSITIVE)
iii
